Vacuum Casting Service

Vacuum Casting is a widely used process in rapid prototyping, typically used for building 10 to 50 pieces of functional prototypes out of broad range of polyurethanes and other polymers.

KESI-3D owns 5 sets of vacuum casting machines, which can cast prototypes with the max dimension up to 2200mm*1200mm *1000mm.

We can accurately reproduce the prototypes with original color, over-mold, inserts molding, texture and geometries from the master model and components. These plastic castings will closely represent the mechanical properties of the intended production parts from a steel mold. One silicone mold can cast about 15 to 20 pieces of parts, depends on complexity, painting or original color, size and other factors in different parts. From machining a master part to casting PU parts usually only takes 7-10 days, or even  less.


Advantages of Vacuum Casting at KESI-3D

1.High production speeds

2.High levels of accuracy (including the surface finish)

3.Cost effective

4.Rubber Parts(Different Hardness Available)

5.Over-mold

6.Insert Molding

Vacuum Casting Materials
Transparent PU, Soft plastic PU, ABS PU, PP/PE PU, Polycarbonate PU, We purchase PU material from Hei-Cast, Axson and BJB companies
  • Colorful Rubber Parts
  • Over-mold
  • Insert Molding
Vacuum casting polyurethanes resins
Material Supplier Material Simulation Strength Shore Flexion(MPA) TC Max Product color description Advantage Disadvantage Shrinkage
ABS-Like
PU8150 Hei-CAST ABS 83 shD 1790 85 Amber,white and black Good resistance 1
UP4280 Axson ABS 81 shD 2200 93 Dark Amber Good resistance 1
PX100 Axson PS chocs 74 shD 1500 70 White/Black Ideal 1
PP-Like
UP5690 Axson PP 75-83 shD 600-1300 70 White/Black Good resistance 1
PU8550 H&K Ltd PP&PE 76 ShD 960 70 White translucent/Black Good resistance 0.3
ColorAble Elastomers
PU8400 Hei-CAST Elastomer 30-85 shA / / Milky white/Black Good Bend 1
T0387 Hei-CAST Elastomer 30-90 shA / / Clear Good Bend 1
Hight Temperature
PX527 Hei-CAST PC 85 shD 2254 105 White/Black High T℃ 105° 1
PX223HT Axson PS/ABS 80 shD 2300 120 Black High T℃ 105° 1
UL-VO
PU8263 Hei-CAST ABS 83 shD 2200 80 Milky white 94V0 flame retarding 1
8263 H&K Ltd. Loaded ABS 83 shD 2200 80 Milky white Coloration TG100° 0.3
Clear-Type
PX522HT Axson PMMA 87 shD 2100 100 Clear Coloration TG100° 0.996
PX521HT Axson PMMA 87 shD 2200 100 Clear Coloration TG100° 0.996
